Igiene e cura della persona                                                              Asciugamani elettrici
        Hygiene and personal care solutions                                                            Hand dryers
        MOCKA





















        Mocka  catturerà  la  vostra  attenzione  per  il  suo  design  stravagante.  Questo   Caratteristiche elettriche / Electrical speci¦cations
        smart dryer, ideato per contesti a medio-alto traffico d’utenza, offre prestazioni
        d’asciugatura eccellenti, tipiche di un jet dryer, allo stesso livello di comfort di un   Numero motori / Number of motors  1
        tradizionale prodotto ad aria calda. Inoltre, la presenza di un termostato garantisce   Motore  AC con spazzole
        massima sicurezza, prevenendo surriscaldamenti, sovraccarichi e cortocircuiti.  Tipo motore / Motor type  Ac brush motor
        Suitable for medium traffic toilets, Mocka has a sophisticated and unconventional   Potenza totale / Total power  1.350 W
        design  since  it  incorporates  a  contoured  water  collection  tray  which  catches   Potenza motore / Motor power  550 W
        droplets. Mocka performs as a jet dryer while offering the highest level of comfort
        as  traditional  devices  do.  It’s  also  safety,  as  it  includes  a  protection  against   Potenza resistenza  800 W (ON-OFF)
                                                                     Heating element power
        overheating, overload and short-circuit.
                                                                     Voltaggio / Voltage  220-240 V
                                                                     Frequenza / Frequency  50-60 Hz
                   PROTEZIONE ANTIBATTERICA - La scocca è realizzata con uno speciale additivo   Isolamento elettrico  Classe II
                   che  rende  l’ABS  antibatterico.  L’attivazione  tramite  sensore  a  fotocellula   Electrical isolation  Class II
                   previene il contatto con l’unità, rendendo l’asciugatura mani più igienica.  Grado di protezione elettrica
                                                                     Electrical class protection  IP44
                   ANTIBACTERIAL PROTECTION - The shell incorporates a special antimicrobial
                   additive to inhibit bacteria growth. The touch-free automatic activation promotes   Struttura / Construction
                   hand hygiene, without the risk of cross-contamination by touching buttons.
                                                                                          ABS antibatterico e anti-UV
                                                                     Scocca / Casing
                   REGOLAZIONE  ARIA  CALDA/FREDDA  -  A  seconda  delle  preferenze      Antibacterial and anti-UV ABS
                   dell’utente, è possibile inserire o disattivare la resistenza elettrica. Il selettore   Filtro aria / Air žlter  Di serie / Standard
                   di temperatura (ON/OFF) è posto nell’incavo del vano d’asciugatura.
                                                                     Dimensioni (LxPxH)
                   ADJUSTABLE  HEAT  CONTROL  -  Depending  on  the  user’s  preferences   Dimensions (WxDxH)  250x165x470 mm
                   or season, the heating element can be switched on or off by pushing the
                   dedicated controller placed on top of the drying zone area.  Peso / Weight  4,7 kg
                                                                                   Funzionamento / Operation
                   SPIE DI CONTROLLO - Il pannello frontale ospita due indicatori a LED, uno   Automatico (sensori a infrarossi)
                   verde ed uno blu, che identificano lo stato di funzionamento dell’apparecchio   Attivazione / Activation  Automatic infrared detector
                   e l’eventuale entrata in protezione della macchina.
                                                                     Velocità dell’aria / Air speed  360 Km/h (in uscita / output)
                   LED INDICATORS - The front panel includes two LED indicators, emitting green
                   and blue light, that shows when the unit is turned on and when an error occurs.  Volume d’aria / Air ±ow  195 m¶/h - 60 l/s
                                                                     Rumorosità (da 1 M)  72 dB
                                                                     Noise level (@ 1 M)
                   SERBATOIO  DI  SCARICO  -  L’acqua  d’asciugatura  viene  canalizzata  in  una
                   vaschetta di recupero alla base del dryer. Il serbatoio è removibile per facilitarne lo   Velocità asciugatura / Drying time  12-15 sec.
                   svuotamento e la pulizia, così da prevenire la formazione di muffe e cattivi odori.
                                                                                  Accreditamento / Accreditations
                   DRAIN TANK - Water is collected in a reservoir with level window. Being
                   removable, the tank can be easily empty and clean, to avoid overflows and   Marchi di qualità / Quality marks  CE, RoHs
                   to prevent mold or bad smells from spreading.
                                                                                 Codici prodotto / Product code
                   FILTRO ANTIPOLVERE (DI SERIE) - Il dryer è fornito di serie con un filtro   Bianco / White  160100
                   antipolvere,  lavabile  in  acqua,  che  garantisce  una  maggiore  purificazione   Grigio metallizzato / Satin-grey  160102
                   dell’aria contro polvere, pollini e batteri.
                                                                     Accessori & ricambi / Accessories & spare parts
                   AIR  FILTER  (STANDARD)  -  The  unit  comes  as  standard  with  a  washable
                   air  filter,  ensuring  protection  against  dust  microparticles  as  well  as  other   Filtro aria / Air žlter  160985
                   pollutants suspended in the incoming air stream.
