Igiene e cura della persona                                                              Asciugamani elettrici
         Hygiene and personal care solutions                                                            Hand dryers
         BAYAMO





















         Bayamo  offre  tutte  le  prestazioni  e  l’efficienza  di  un  jet  dryer  con  il  medesimo   Caratteristiche elettriche / Electrical speci¦cations
         comfort d’asciugatura di un tradizionale prodotto ad aria calda. Un puro concentrato
         di  tecnologia  e  funzionalità,  senza  sacrificare  la  sicurezza.  L’unità  incorpora  un   Numero motori / Number of motors  1
         sensore in grado di rilevare la temperatura ambiente e regolare automaticamente il   Motore AC con spazzole
         calore della resistenza, così da evitare inutili sprechi di energia.  Tipo motore / Motor type  Ac brush motor
         Blowing water from hands in less than 10 seconds, Bayamo is one of the most   Potenza totale / Total power  1.900 W
         efficient and powerful ‘hands-in’ dryers on market. Super-reliable and perfect to   Potenza motore / Motor power  900 W
         handle heavy crowds in high traffic washrooms, this device combines top-notch
         technology  with  cutting-edge  functionality.  It  incorporates  an  air  sensor  which   Potenza resistenza  1.000 W (ON-OFF)
                                                                      Heating element power
         detects ambient temperature, then automatically adjusting the heater.
                                                                      Voltaggio / Voltage  220-240 V
                                                                      Frequenza / Frequency  50-60 Hz
                    IGIENE GARANTITA - La scocca in ABS è realizzata con uno speciale additivo   Isolamento elettrico  Classe II
                    antibatterico e anti-UV. Nel dryer sono presenti due dispositivi LED a raggi UV   Electrical isolation  Class II
                    che sterilizzano il flusso d’aria nel punto d’aspirazione ed in quello d’uscita.  Grado di protezione elettrica
                                                                      Electrical class protection  IP44
                    ENHANCED  HYGIENE  -  The  shell  incorporates  anti-microbial  and  anti-UV
                    technology, inhibiting the growth of bacteria. It is also equipped with two UV   Struttura / Construction
                    LED devices which sanitize the air stream both in the air intake and output area.
                                                                      Scocca               ABS antibatterico e anti-UV
                                                                      Casing               Antibacterial and anti-UV ABS
                    PANNELLO DI REGOLAZIONE INTEGRATO - Specifici selettori consentono di
                    accendere o spegnere il dryer (ON/OFF); attivare o disattivare la resistenza;   Filtro aria  / Air žlter  Di serie / Standard
                    regolare la potenza del motore scegliendo tra due velocità dell’aria (HIGH/LOW).
                                                                      Filtro EPA E11 / EPA E11 Filter  In opzione / As option
                    INTEGRATED  ADJUSTMENT  PANEL  - In-built  switchers  allows  to  choose  the
                    operation  mode.  You  can  activate/deactivate  the  unit  (ON/OFF);  switch  the   Dimensioni (LxPxH)  300x220x687 mm
                    heating element ON/OFF for instant hot air flow; adjust airflow speed (HIGH/LOW).  Dimensions (WxDxH)
                                                                      Peso / Weight        9,5 Kg
                    MONITORAGGIO CICLO D’ASCIUGATURA - Un display LED posto sulla sommità
                    dell’apparecchio consente di controllare il tempo d’asciugatura. Due spie luminose   Funzionamento / Operation
                    identificano lo stato d’accensione e l’eventuale entrata in protezione del dryer.  Automatico (sensori a infrarossi)
                                                                      Attivazione / Activation
                    DRYING CYCLE QUICK CHECK - A LED screen is placed on top of the dryer,   Automatic infrared detector
                    allowing the user to quickly check the drying cycle status, while two LED   Velocità dell’aria
                    indicators show when the unit is working and when an error occurs.  Air speed   95 m/s (in uscita / output)
                                                                      Volume d’aria / Air ±ow  190 m¶/h
                    SERBATOIO  DI  SCARICO  -  Bayamo  incorpora  una  vaschetta  di  recupero  con
                    funzione “troppo pieno” che cattura l’acqua d’asciugatura. Il serbatoio è estraibile,   Rumorosità (da 1 M)
                    facile da svuotare e pulire, per prevenire la formazione di muffe e cattivi odori.  Noise level (@ 1 M)   72 dB
                    DRAIN TANK - Bayamo incorporates a built-in drain tank with overflow pump   Velocità asciugatura / Drying time  10 - 12 sec.
                    that catches water droplets coming off users’ hands. Being removable, the
                    tank can be easily empty and clean to both avoid overflows and bad smells.  Accreditamento / Accreditations
                                                                      Marchi di qualità / Quality marks  CE, RoHs
                    FILTRI ARIA / EPA - Il dryer è fornito di serie con un pre-filtro d’aspirazione
                    lavabile  in  acqua.  In  opzione,  è  possibile  avere  un  filtro  EPA  E11,  che   Codici prodotto / Product code
                    garantisce una maggior purificazione dell’aria contro polvere, pollini e batteri.
                                                                      Bianco / White       160010
                    AIR/EPA FILTERS - The dryer comes as standard with a washable air pre-  Grigio metallizzato / Satin-grey  160012
                    filter. It can also incorporate a replacable EPA filter, which traps up to 97,66%
                    of dust micro-particles suspended in the incoming air stream.  Accessori & ricambi / Accessories & spare parts
                                                                      Filtro EPA E11 / EPA E11 žlter  160015
                                                                      Box per žltro EPA / Box for EPA žlter  160990
